Features:
1. Applied to adjusting sag in erecting wire and sagging
2. Forged of high strength aluminum alloy, compact and light weight
3. Model number with “G” stands for clamp with protection hook device
4. Clamp with protection hook devices, strength test up to 3 times and no damage
to conductor, especially suitable for power distribution and transmission companies
Model |
Rated Load |
Applicable Conductor |
Max Opening |
Weight |
SKL-7 |
7kN |
LGJ25-70 |
14mm |
1.0kg |
SKL-15 |
15kN |
LGJ95-120 |
18mm |
1.4kg |
SKL-25 |
25kN |
LGJ150-240 |
24mm |
3.0kg |
SKL-40 |
40kN |
LGJ300-400 |
32mm |
4.0kg |
SKL-50 |
50kN |
LGJ500-630 |
37mm |
7.4kg |
SKL-50G |
50kN |
LGJ500 |
37mm |
7.2kg |
SKL-50GA |
50kN |
LGJ630 |
37mm |
7.4kg |
SKL-60G |
60kN |
LGJ700 |
44mm |
11.0kg |
SKL-70GA |
70kN |
LGJ800 |
44mm |
11.5kg |
SKL-75G |
75kN |
LGJ900 |
46mm |
16.0kg |
SKL-80GA |
80kN |
LGJ1000 |
46mm |
16.5kg |
|
100kN |
LGJ1250 |
52mm |
22.0kg |
|
100kN |
LGJ1520 |
52mm |
22.2kg |
