The MINI Series Drive-Type Hydraulic Torque Wrench is specially designed for bolting applications in restricted and hard-to-access working environments. Featuring a compact body, front-mounted reaction arm, and lightweight aluminum-iron alloy construction, it delivers high torque accuracy and reliable performance while minimizing space requirements.
BETE MINI Series Drive-Type Hydraulic Torque Wrench is engineered for industrial bolting applications where conventional hydraulic torque wrenches cannot be easily operated due to limited working space. Its compact structure and innovative front-mounted reaction arm design significantly reduce the overall longitudinal dimension of the tool, making it ideal for flange connections, equipment maintenance, and structural bolting in confined environments.
Product Features
◢ Accuracy: ±3%
◢ One-piece fuselage made of aluminum-iron alloy, featuring light weight, high strength, and high toughness
◢ Front-mounted reaction arm design: with a small longitudinal dimension, it is more suitable for narrow spaces
◢ The reaction arm is positioned at the square drive of the drive shaft, eliminating eccentric load
◢ 360°×180° rotating oil pipe joint, allowing unrestricted use regardless of space conditions
◢ Customizable force arm according to customers' actual needs
Customizable force arm according to customers' actual needs.
| Model | Torque Value (N.m) | Nut Size (M) | H (mm) | W (mm) | L (mm) | R (mm) | Weight (kg) | Drive Shaft |
| MINI-07 | 104-1040 | 14-27 | 106.9 | 45.3 | 105.2 | 25 | 1.4 | 3/4" |
| MINI-1 | 174-1741 | 18-36 | 124.9 | 55.2 | 127.9 | 28.6 | 2 | 3/4" |
| MINI-3 | 402-4025 | 24-48 | 160.2 | 73.7 | 165.9 | 38.1 | 4.3 | 1" |
| MINI-5 | 726-7267 | 30-56 | 188.2 | 85.9 | 119.5 | 47.2 | 7.1 | 1-1/2" |
| MINI-8 | 1052-10521 | 36-64 | 212.7 | 98 | 224.2 | 52.5 | 9.4 | 1-1/2" |
| MINI-10 | 1592-15921 | 42-72 | 236 | 110.5 | 252 | 60.3 | 13.3 | 1-1/2" |
